As of the deadline for this Newsletter, the Observatory had not received its 1996 budget. Although unfortunate, this is not surprising in that the NSF itself has yet to be funded for 1996. The current expectation is that this year's budget will be settled in late April. Because the expected budget level required a reduction in personnel at the NRAO, the steps required were taken in mid-March. The overall loss to NSF-funded operations staff was six percent. Half of the staff positions lost were open positions; the other half was made up of employees who were laid off, or had their hours reduced to part-time, or were transferred to fill open positions in projects funded by other agencies.
Other measures were required beyond the reduction in staff to meet the expected 1996 budget. Unless another source of funds can be found, there will be no budget for equipment to improve the instrumentation at the telescopes or to address the Observatory computing needs. This will be the first year in the history of the Observatory that there will be no such research equipment budget. The maintenance programs at the telescopes will continue, but at minimum levels. Two offers of Jansky postdoctorals were made instead of the usual three, and the number of graduate students resident at the Observatory has been reduced from thirteen to three. Budgets for the library, for materials, supplies, and travel have all been cut.
No cuts are anticipated, however, in the support given to telescope users for travel and page charges. We recognize that the current poor funding for research is widely shared in the community. We consider it essential to preserve as best as possible the system that allows NRAO users with modest grant support, or no grant support, to observe at the NRAO and publish their results with only minimal resources needed from their home institutions.
Users should be confident that the NRAO will do everything possible to continue to provide the facilities and service they have come to expect. Our long range goals for new facilities remain unchanged: complete the Green Bank Telescope, begin the Millimeter Array, and engage the user community in planning for the VLA Upgrade.
P.A. Vanden Bout
The NSF is now considering whether to include the MMA as a new start in the Major Research Equipment account for FY 1998. We are hopeful of a successful outcome as the timeliness of the MMA is now widely appreciated in the U.S. scientific community and abroad.
The database of site-testing data now includes atmospheric transparency and stability measurements made both on Mauna Kea and in Chile for a year or more. This is sufficient information to facilitate a comparison of the two sites so that we can now assess how much observing time will be available on the sites as a function of frequency and as a function of interferometer baseline. The results of this analysis will be combined with a study of long-term climatic trends, and with an operating model for the MMA on the two sites to lead us to a prioritization of the sites. Our goal is to have this site choice document available for review by the MMA committees and others in the third quarter of 1996.
Discussions continue with potential partners for the MMA. Recently the focus of these discussions, both with potential international partners and for the possible involvement of other government agencies, has been on an expansion of the MMA capabilities so as to provide enhanced scientific opportunities for users of the MMA. Since the proposed MMA enhancements to longer baselines and higher frequencies are very much in accord with the recent recommendations of the Millimeter Array Advisory Committee (the MAC), we hope to cement suitable partnership arrangements in the near future. We will report progress on these initiatives in future issues of the Newsletter.
Current MMA information, including summaries of the site test data, may be obtained from http://www.tuc.nrao.edu.
The Single Dish group proceeded with work towards a single dish analysis package for the GBT. A significant milestone in this development will be an initial test of some of the GUI components, scheduled to occur in June and July. The GUI components are being implemented using the variant of glish, glishtk, which has the tk widgets bound in. One considerable advantage of the use of glishtk is that GUI components may be developed interactively, from the command line, and other components, such as the tablebrowser, called directly via simple glish commands.
AIPS++ is being used for the immediate analysis and ultimate reduction of data from a multi-beam HI survey using the Parkes telescope. In connection with this effort, David Barnes of the survey team spent eight weeks working with the SD group in Charlottesville.
Wim Brouw (ATNF) froze the design of the Measures system (used for units, quantities and coordinates) and worked on completing the implementation. Completion of all major features except high precision VLBI support is expected in April. Parts of the code are now being reviewed, as is standard for all code developed in AIPS++.
The AIPS++ infrastructure was improved in a number of areas in response to the requirements arising from applications development:
We have completed a port to the HP/UX compiler, and are now in the process of porting to the GNU Project g++ compiler. We know from preliminary investigations that this port will work but a number of changes to AIPS++ are required. We believe this effort is well worth while since it will give us the ability to run on many platforms.
P.A. Vanden Bout
The partnership will focus on a number of select areas, which include:
NCSA plans to provide time and accounts on the large machines for peer reviewed research projects and official NRAO projects such as the Green Bank Telescope or the Millimeter Array. This time will be managed by NRAO. Projects which require high performance computing resources found at NCSA are especially encouraged, as are development projects which lead to significant improvements in performance or functionality for community application codes. NRAO users and researchers will continue to be able to directly apply for allocations of time through the normal NCSA peer review process outside of the agreement between NRAO and NCSA.
Currently, NRAO is using NCSA facilities to perform dynamical modeling calculations for the Green Bank Telescope, and is also in the process of completing an AIPS port to the computing systems at NCSA. As experience is gained at NRAO with NCSA's facilities, procedures will be worked out to enable NRAO users with need for high performance computing to access the facilities at NCSA. Users wishing to learn more about the facilities at NCSA can find detailed information on the WWW at http://www.ncsa.uiuc.edu/.
ON ASTRONOMICAL DATA ANALYSIS SOFTWARE AND SYSTEMS
The Program Organizing Committee for ADASS '96 has the following members: Rudi Albrecht (ST-ECF/ESO), Roger Brissenden (SAO), Tim Cornwell (NRAO), Dennis Crabtree (DAO/CADC), Bob Hanisch - Chair (STScI), Gareth Hunt (NRAO), George Jacoby (NOAO), Barry Madore (IPAC), Jonathan McDowell (SAO), Jan Noordam (NFRA), Dick Shaw (STScI), Karen Strom (U. Mass.), and Doug Tody (NOAO). The Local Organizing Committee is chaired by Richard Simon and has participants from NRAO, the University of Virginia Depart-ment of Astronomy, and the University of Virginia Computer Science Department.
The preliminary program for the Conference will be completed in the next few weeks, so watch the Conference home page for further details as they become available: http://www.cv.nrao.edu/adass/. For further information and/or to be placed on the mailing list for the conference, please send a request to either firstname.lastname@example.org or to:
Mark your calendar now and plan to attend ADASS '96.
R. A. Simon
[This is an update of the article by Brown and Smiley, NRAO Newsletter No. 61, 1 October 1994. Note the changes in the example session. See also a description in the AIPS Cookbook, Appendix Z.]
There is now a reasonably simple procedure in place by which users may make slides of their images from the NRAO telescopes. We certainly encourage users to make use of the facility both for their own professional research purposes and also as an aid to their instructional activities. Single images will usually be printed directly to the 35 mm slide format; multi-panel images will be printed to 4x5 film in addition to the 35 mm format.
The procedure for making slides is described below. The slide will be made in a day or two and returned to the individual submitting the image file. Among the reasons the NRAO offers this service to staff and users is that it enables us, in principle, to enhance the NRAO library of astronomical images. With permission of the astronomer submitting the image to be made into a slide, we will make a master copy of the slide for the library and ask for a brief image description. The NRAO will make the image available for scientific and educational purposes, noting in material sent with the slide the name of the observer(s) responsible for producing the image. In return for permission to include the slide in the library, the NRAO will provide any of the observers involved with copies of the slide, or prints of it, at no charge for as long as the image remains in the library.
To make a slide of your image:
A typical ftp session would be the following:
ftp ftp.cv.nrao.edu login anonymous password <your_full_e-mail_address> cd pub/slides/slides put my-image.ps quit
As can be seen in the accompanying recent photograph of the structure, the elevation wheel is completely assembled and welded and sixteen of the counterweight boxes are installed. Three of the 10 trusses of the box structure already have been moved from the trial erection area onto the structure.
However, what cannot be seen in the photo are all the pockets of activity being accomplished on the ground around the structure. For instance, on the northwest side of the antenna, the box structure trial erection is now complete. Over the next couple of months, this huge assembly will be moved from the ground onto the structure in a series of modular lifts. In addition, the upper feed arm (the section of the feed arm which ultimately will be above the receiver room) has been assembled on the ground near the COMSAT RSI warehouse and is awaiting welding. This erection will allow the feed and subreflector positioning mechanisms to be tested and calibrated prior to lifting the assembly onto the antenna.
On the south side of the antenna is the back-up structure (BUS) assembly pad, where sixteen of the BUS ribs have been trial assembled (the center rib plus eight left and seven right) from hoops 15 to 33 (when complete there will be 57 total ribs, the center plus 28 right and 28 left, extending from the apex at the base of the feed arm for 44 hoops to the outer edge of the dish). Essentially all the interconnecting beams and fill-in members are also in place. Right now on site, there are approximately 4000 of the 7100 required members for the reflector BUS. One of the interesting construction staging problems facing COMSAT RSI is cataloging and keeping track of all the parts on site (imagine laying out over 7000 Tinker Toy parts on your floor and being responsible to find a particular one when you need it). As the pieces are put together, the magnitude of the completed structure and of the erection job becomes more evident every day.
Main reflector panel production continues at the COMSAT RSI Sterling, Virginia plant. Delivery of the subreflector (an ellipsoid 7.55m x 7.95 m) and the feed arm servo hardware were slipped from last quarter into the spring, making the next few months at the construction site full of anticipation.
Earlier this year the Naval Research Laboratory informed us that they were no longer able to continue funding the Interferometer. We are searching for other sources of support for this unique and important instrument, but as of this writing, operations are scheduled to end by the beginning of April, 1996.
This change of policy will inconvenience some observers, but it also opens a unique opportunity. Survey programs that require larger blocks of time with a fixed equipment configuration will be a good match to the new scheduling system. I encourage anyone who has such a project in mind to submit a proposal. Survey proposals will be refereed in the usual way, and the more highly rated will be scheduled beginning in June.
F. J. Lockman
The up/down link phase stability was measured and found to be good. The wide band down link data were written to VLBA format tape and sent to the VLBA correlator where the data will be correlated to verify the data format and quality.
G.I. Langston and L.R. D'Addario
The most current version of observe is 3.2.28, dated 1996.02.27. This version has the updated VLA calibrator database, the new X-band defaults, better calibrator searches (uses band and array configuration to find possible calibrators), an alternative to the dreaded keypad, and several bug fixes. Please read ANNOUNCE.V3 (located at the WWW URL: ftp://ftp.aoc.nrao.edu/ pub/observe) to find out more details about the changes.
The latest version may be obtained via anonymous ftp from ftp.aoc.nrao.edu or from the WWW URL: ftp://ftp.aoc.nrao.edu/pub/observe/.
Configuration Starting Date Ending Date Proposal Deadline C 09 Feb 1996 29 Apr 1996 2 Oct 1995 DnC 10 May 1996 25 Jun 1996 1 Feb 1996 D 28 Jun 1996 30 Sep 1996 1 Feb 1996 A 18 Oct 1996 30 Dec 1996 3 Jun 1996 5pm ET BnA 10 Jan 1997 27 Jan 1997 1 Oct 1996 5pm ET B 31 Jan 1997 12 May 1997 1 Oct 1996 5pm ET CnB 23 May 1997 09 Jun 1997 3 Feb 1997 5pm ET
The VLA is currently scheduling two large surveys. One will be done at nighttime in the DnC and D configurations and will be essentially completed by the end of September, 1996. The other covers the north galactic cap (07h-17h) in the B configuration. Observing time in those configurations and LSTs will be much reduced over past practice. On the other hand, observations disjoint with the surveys in those configurations will have more time available for scheduling than has previously been the case.
The maximum antenna separations for the four VLA configurations are: A-36 km, B-11 km, C-3 km, and D-1 km. The BnA, CnB, and DnC configurations are the hybrid configurations with the long north arm, which produce a round beam for southern sources (south of about -15 degrees declination).
Q1 Q2 Q3 Q4 1996 C D D A 1997 B C C,D D 1998 A B C C,D 1999 D A B C 2000 C,D D A B
Observers should note that some types of observations are significantly more difficult in daytime than at nighttime. These include observations at 327 MHz (solar and other interference; disturbed ionosphere, especially at dawn), line observations at 18 and 21 cm (solar interference), polarization measurements at L band (uncertainty in ionospheric rotation measure), and observations at 2 cm and shorter wavelengths in B and A configurations (tropospheric phase variations, especially in summer). They should defer such observations for a con-figuration cycle to avoid such problems.
In 1996, the A configuration daytime will be about 14h RA and the B configuration daytime will be about 22h RA.
Time will be allocated for the VLBA on intervals approximately corresponding to the VLA configurations from those proposals in hand at the corresponding VLA proposal deadline.
After several tests of the RFI environment at X band, new 3.6 cm default frequencies of 8435 and 8485 MHz were assigned in both OBSERVE (see entry in this newsletter) and in the VLA on-line system on February 14. This selection maintains the majority of the band within the Deep Space Research allocation of 8400-8500 MHz. 8450-8500 MHz is allocated to space research including space to earth transmission that is not strictly limited to deep space satellites. The range 8500-9000 MHz is allocated to airborne radar, but most of the usage seems to be in the range 8600-10500 MHz. So, for the near future, the proposed defaults should be relatively free of both local and external RFI.
We completed making the "Socorro Visitor's Information Package" accessible via the Socorro Web page. The list of public workstations and the Visitor's registration form were already accessible on-line; to this we have added information about current and future workstation bookings. This information system should greatly assist prospective visitors to the AOC in planning their visit.
The AOC has purchased two Sparc Ultra I machines, which will replace two of the current Sparc IPX visitor's workstations. We hope that with these machines we can better serve the needs of scientists with very large VLBA and VLA projects. Tests using the AIPS "dirty dozen test" (DDT) indicate that for typical AIPS applications these machines are faster than our IBMs - currently our fastest machines - by a factor of 1.6. The new machines will be installed during the second half of March, and will be available to visitors and local staff from the beginning of April.
G.A. van Moorsel
Recently, there have been requests to visit NRAO in Socorro, from students who have not previously been to the New Mexico NRAO facility. We are always happy to have new VLA and VLBA users in Socorro. In that connection, we restate our policy regarding students who are first-time users of the VLA or VLBA and of the AOC data reduction facilities:
First time student observers must be accompanied by their faculty advisor or a senior researcher for at least half of their first observation or data reduction visit to the AOC. Attendance at the summer schools or similar conferences held in Socorro does not waive this requirement. Once a student has gained sufficient experience, he or she need not be accompanied by an advisor on subsequent visits. VLA/VLBA staff assistance will be provided as needed and as requested on the VLA/VLBA observing application cover sheets.
Please note and use the new e-mail address below when arranging a visit to the NRAO in New Mexico.
For your convenience, a Visitor Reservation Form is available via the Socorro WWW home page. This form can be filled out interactively and sent to the reservation office via e-mail. This form will save you time in arranging your visit. We encourage everyone to use the form if possible.
There has been considerable activity in the area of the 43 GHz (Q band) system at the VLA. The principal action has been the outfitting of three more antennas with new Q band receivers, bringing the total to 13. Also, all the Q band antennas are having their surfaces adjusted using holographic measurements of the surface errors. Initial results indicate that this process can improve aperture efficiencies by up to 40 percent. The net effects of these improvements are: (i) significantly better u-v coverage, and (ii) improved sensitivity. We estimate that the sensitivity should improve to about 0.3 mJy in one hour using two IFs, two polarizations, and a 50 MHz bandwidth per IF at 43 GHz.
There also has been activity related to phase calibration techniques at high frequency at the VLA. A "fast-switching" mode has been tested with a minimum total cycle time of 40 seconds. This method has been shown to minimize tropospheric phase variations on baselines longer than about 300 m. Contact C. Carilli for more details.
A final important point concerns the placement of the Q band antennas in the upcoming A array. For this A configuration, in a good observing season, we will occupy the ends of the arms to obtain maximum resolution. The remaining antennas will be distributed to produce a good beam at this resolution. It is our plan that in succeeding configurations of this cycle, we shall maintain, at least roughly, the scalings to which we are accustomed in other bands. That is, in this cycle at least, objects requiring a resolution of about 0.15" should be proposed for B configuration, rather than A configuration as they were last cycle.
The current plan involves putting ten antennas in a modified "spiral" pattern (scaled from the design employed in the last D configuration). One of the three additional Q band antennas will be placed at an inner station, to improve coverage of the short spacings, while the other two will populate the outermost stations, to improve coverage on the longest spacings and to attain maximum resolution. For the A array, a resolution of 30 mas will be possible, and u-v coverage should be reasonable down to baselines of 300 m. The detailed antenna placements are summarized in the table below. We also plan to use this configuration or some minor variant of it in the B, C, and D configurations of this cycle.
(Oct - Dec 1996)
North West East 9 9 9 8 - - - 7 - - - 6 5 - - - 4 - - - 3 2 - - 1 1 1
In the middle of March, the correlator software group released a new version of the online software with several improvements. Source and frequency subarraying now are available, the 2K FFT is now implemented correctly, the ability to load and test various window functions is also available now. Users should read Jon Romney's recent release notes and observing guidelines (available from the NRAO home page) for more details. With this software release the correlator group is positioning itself to implement various options required for Space VLBI.
As was reported in the release notes for the latest version of the software, a bug was found and fixed. This bug existed since the day the correlator was turned on. The bug resulted in the output time labels of the visibility data being mislabeled by one correlator tick (131 millisec). The effects of this bug were not catastrophic, resulting in small phases errors (residual fringe-rate multiplied by 131 millisec) which could be almost completely corrected by self-cal or phase-referencing. For more details see the release notes mentioned above.
Proposals for VLBI Network observing are handled by the NRAO. In particular, only one further Global Network session is planned for 1996, and it is expected that Network observing in 1997 will be dominated by the needs of Space VLBI with VSOP. The currently planned session is 16 October to 06 November, with a proposal deadline of 01 June 1996. Observing bands for this session will be 1.3 cm, 6 cm, and 3.6/ 13 cm. Further information about this session may be transmitted on the VLBI e-mail exploder (send subscription requests to email@example.com).
It is recommended that proposers use a standard coversheet for their VLBI proposals. Fill-in-the-blanks TeX files are available by anonymous ftp from ftp.cv.nrao.edu, directory proposal or via the VLBA home page on the WWW. Printed forms, for filling in by typewriter, are available on request from Betty Trujillo, Socorro.
Any proposal requesting NRAO antennas and antennas from two or more institutions in the European VLBI network constitutes a Global proposal. Global proposals MUST reach BOTH Network's Schedulers on or before the proposal deadline date; allow sufficient time for mailing. In general, fax submissions of Global proposals will not be accepted. Proposals requesting use of the Socorro correlator must be sent to NRAO even if they do not request the use of NRAO antennas. Proposals for the use of the Bonn correlator must be sent to the MPIfR if they do not request the use of any EVN antennas. For Global proposals, or those to the EVN alone, send proposals to:
For proposals to the VLBA, or Global proposals, send proposals to:
Following a brief commissioning period, observations with the 8-Beam 1.3 mm array receiver began on February 22nd. The 4 X 2 beam cluster can track parallactic angle with an arbitrary position angle offset. Considerable effort has been devoted to improving the noise performance of the 8 receivers. While there is still room for improvement, the present performance of the receiver represents a substantial gain over the existing dual beam system for mapping extended regions.
The principal observing mode with the 8-Beam receiver is the on-the-fly (OTF) mode. Two types of OTF images can be acquired. In "optimal" 8-Beam OTF observing, the map field is sampled using a two-step process. The array is canted at an angle relative to the scanning direction (RA or Dec) so that adjacent beams sample independent regions of the field while the array is rastered. Once an array "footprint" is fully sampled, the array is moved to an adjacent region of the map field to continue the rastering process. In "conventional" 8-Beam OTF observing, the array is simply scanned over the map field to achieve full sampling. Conventional 8-Beam OTF maps sample almost all points eight times, resulting in a high signal-to-noise image at the expense of time efficiency. Optimal 8-Beam OTF should be approximately two to three times more time efficient than OTF observing with the single-beam, dual-channel system.
The figure shows in two plots the CO 2-1 intensity measured toward the OMC-1 region for LSR velocities of 7.0 and 9.0 km/s (indicated in the upper right of each panel). The beam size is indicated in the lower right corner of the first panel. This 14'X14' map was acquired using the "conventional" 8-Beam OTF method. Total map time was approximately 1.75 hours, and the resulting single channel rms noise was 0.35K. (The figure is not included in this HTML version of the NRAO Newsletter No. 67.)
Documentation describing the use of the 8-Beam receiver is currently being prepared. Prospective observers are encouraged to contact Jeff Mangum (firstname.lastname@example.org) for information and advice on observing strategies.
J.G. Mangum, D.T. Emerson, and J.M. Payne for the Tucson Group
We continue to support remote observing with the 12 Meter Telescope. Observers are reminded to contact the observatory staff well in advance of their scheduled observing to discuss the suitability of remote observing for their particular experiment. In addition, it is important that remote observers:
We are working on incorporating information regarding remote observing policy within the Tucson link of the NRAO home page (http://www.nrao.edu).
D.T. Emerson, J.G. Mangum and S.J.E. Radford
NOTE TO 12 METER TELESCOPE OBSERVERS
In order to make the best use of the telescope, prospective and scheduled observers are strongly encouraged to contact the Friend of the Telescope, Jeff Mangum, for advice regarding their proposed experiments. This is of particular importance for observers conducting 8-Beam and on-the-fly experiments given the complexity of these observing modes. Send questions via e-mail to email@example.com or by voice to 520-882-8250 ext.113.
J.G. Mangum and D.T. Emerson
