Radio and X-ray Image of G21.5-0.9

A radio and¡ X-ray composite image of the pulsar-powered supernova remnant, G21.5-0.9, includes data from the NRAO Very Large Array (blue) and the Chandra X-ray Observatory (red). The remnant is what remains of a supernova that exploded in our Galaxy about 1000 years ago. The core of the original star has collapsed to an incredibly dense neutron star or pulsar, which spins rapidly and emits an energetic wind of particles and magnetic field that energizes the filamentary nebula visible in the radio and in the X-ray. Although the pulsar is not seen directly, we can infer that the pulsar is located inside the bright X-ray region that is seen here as the central orange spot.

Legacy Astronomical Images

NRAO/AUI/NSF does not hold full copyright for this image. Contact the archivist for details.

Legacy Astronomical Image

G215-09

M. Bietenholz (Hartebeesthoek Radio Observatory, York University), N. Bartel (York University), H. Matheson (University of Manitoba), S. Safi-Harb )

Very Large Array (VLA)

2006-09-09

continuum

C

6 cm

5.0 GHz

RA 18:33:34.000, Dec: -10:34:8.000

0.043333 x 0.033333 degrees
